Nd:YAG Crystal

Industry category：
Lasers Technology & Intelligent Manufacturing
Product range：
Laser Material and Component
Application field：
Advanced Manufacturing,Sensing & Measurement,Medical, Universities and Research Institutes
Register Invitation

Product Picture:

Product Presentation:

Doping Ratio: 0.1%~1.3at% Orientation: <111> or <100> or <110> Dimensions: Diameter: 2~15 mm, Length: 3~220 mm Flatness: < λ/10 @ 632.8 nm Surface Quality: < 10/5 [S/D] Parallelism: < 10” Perpendicularity: ≤ 5' WFD: < λ/10 @ 632.8 nm Extinction Ratio：> 30 dB Coating: AR-Coating (R<0.10% @1064nm) Laser Damage Threshold: > 800 MW/cm2 for 1064nm, 10ns, 10Hz
